Fixed Picture
M&T Design Home Improvement LLC offers Fixed Picture Windows that provide hurricane protection, energy efficiency, and sleek, modern designs to enhance your home or business.
Impact Resistant Fixed Picture Window
- Meets HVHZ. LMI Rated
- DP= +/-65 PSF
- Sizes: 48″ x 84″ / 36″ x 108″ / 24″ x 168″
- Slim structure to maximize glass view and day light opening
- Extrusions are 2-3/16″ deep to have the minimal impact on interior finish during retrofit
- Shapes and Figures available, colonials for design freedom
- Meets ANSI Z97.1 (Human fall/impact protection)
- Machine glazed with silicone GE 2000/DS795
- Laminated Heat Strengthened Glass with 0.09 thick PVB as interlayer
- Clear, tinted, or reflective glass. Low-e glass for enhanced Solar Heat Gain Coefficient while allowing maximal transparency and visual light transmittance
- Silicone glazing gasket and stainless steel screws
- Powder coat finish. Standard and custom colors. Meeting AAMA 2004 as standard finish (5 years warranty) with possibility to upgrade to AAMA 2605 (10 years warranty)
- Aluminum 6063T6 structure
FL #41889.1 LMI
Impact Resistant Fixed Picture Window
Max. Dimensions: 48” x 84”
Meets Florida Building Code for High Velocity Hurricane Zone.
Large missile ratedMatches with MG-200 and MG-300 single hung and horizontal
roller seriesFigures and arches are available
Glazing applied with high strength silicone for elevated resistance
to impact and cyclic loads2-7/8” deep frame. Glazing capabilities: Heat strengthened laminated 7/16” and Insulated glass up to 13/16” thick. Enhanced thermal performance with low E coating available
Design Pressures up to +/- 100 PSF
Powder Coating aluminum finish for superb quality and environmentally friendly operation. Meets AAMA 2604 exigencies (5 year warranty) AAMA 2605 is also available (10 year warranty)
Florida Product Approval
Impact Resistant Fixed Picture Window
- Versatile series that can be manufactured as fixed glass window, louver or a combination of both
- Meets Florida Building Code for High Velocity Hurricane Zone.
Large and Small missile rated - Includes intermediate horizontals (verticals depending on orientation)
- Mitered cuts and assembly via fixed corner and alignment keys.
For figures and arches, corner keys and alignment keys are adjustable. Drained pockets with Hi-Flo® valves and screw covers - Glazing capabilities 7/16″, 9/16″ Laminated and 1″ insulated laminated
- Max Dimensions as Fixed Window: 48″ x 180″ Design Pressures: +85/-120 PSF
- Max. Dimensions as Louvers 60″ x 168″ Design Pressures: +/- 80 PSF
- Louvers compatible with MG 3000 door and impact rated
- Powder Coating aluminum finish for superb quality and environmentally friendly operation. Meets AAMA 2604 exigencies (5 year warranty) AAMA 2605 is also available (10 year warranty)
FL #40676.1 LMI – FL #40676.2 SMI
Impact Resistant Fixed Picture Window
Heavy-gauge aluminum T6 alloy
Stainless steel assembly screws
Double weather-stripping
Extruded snap-on glazing beads
Flange Frame
2 3/4″ Frame Depth
Maximum Width: 37″
Maximum Height: 76″
Maximum Size:
37″ x 76″ (LMI)
30″ x 70″ (SMI)
Design Pressure: +70/-75 psf
5/16″ HS/HS
Stainless steel operator
Multipoint lock
Nesting handle
NFRC Certified
Florida Product Approval: Large Missile and Small Missile
7/8″ TMP/HS and 7/16″ HS/HS
Energy efficient LoE coatings
Equal leg adapter
Glass with argon
Extruded double-applied 1″ colonial muntins
Available Mutins:
1″ Flat-Flat
1″ Ogee-Flat
1″ Ogee-OgeeAvailable in Colonial, Brittany 6, Brittany 9
Impact Resistant Fixed Picture Window
Heavy-gauge aluminum T6 alloy
Stainless steel assembly screws
2 3/4″ Frame Depth
Maximum Width: 72″
Maximum Height: 120″
Maximum Size:
36″ x 120″ (LMI)
24″ x 120″ (SMI)
(Large Missile) Design Pressure: +80/-90 psf
7/16″ HS/HS
Concealed fasteners
Clear, Gray, Bronze, Green, Azuria, Obscure (White Interlayer)
Flange frames
Florida Product Approval: Large Missile and Small Missile
Equal leg adapter
Energy efficient LoE coatings
Extruded double-applied 1″ colonial muntins
Available Muntins:
1″ Flat-Flat
1″ Ogee-Flat
1″ Ogee-OgeeAvailable in Colonial, Brittany 6, Brittany 9
Architectural shapes
Work Examples
