Impact Resistant Residential Entry Door

• Meets Florida Building Code for High Velocity Hurricane Zone.
  Large Missile rated

• Available configurations: X, XX, OX, OXO, OXXO, O

• Maximum dimensions: X configuration: 48” x 120”, OXXO config: 156” x 98”

• Side-lites with matching top and bottom horizontal lines

• Stand along Single Side-lites available

• High Bottom Rail Door available

• Aluminum, Ball-Bearing (Stainless Steel) and Continuous Aluminum Geared Hinges available

• Max. Design pressures: +/-80 PSF

• Glazing capabilities 7/16” laminated and 1” insulated laminated.
  Enhanced thermal performance with low E coating available

• Multiple glass lites per door panel (intermediate horizontals) allowing combinations of privacy, clear or tinted glass

• Powder Coating aluminum finish. Meets AAMA 2604 exigencies (5-year warranty) AAMA 2605 is also available (10-year warranty)

• Industry Standard Hardware preparation: options for 3 Point Locks and Smart Locks

• Flush Bolts at top and bottom

• Muntins and Raised Grid for design freedom

​Florida Product Approval

FL #26942.1 LMI

Impact Resistant Residential Entry Door

• Meets Florida Building Code for High Velocity Hurricane Zone.
  Large Missile rated

• Available configurations: X, XX, OX, OXO, OXXO, O

• Maximum dimensions: X configuration: 48” x 120”, can be combined with MG-3000 Sidelites for a maximum dimensions of 156″ x 120″

• Side-lites with matching top and bottom horizontal lines

• High Bottom Rail Door available

• Ball-Bearing (Stainless Steel) Hinges available

• Max. Design pressures: +/-80 PSF

• Glazing capabilities 7/16” laminated, 1” insulated laminated and 1″ solid aluminum panel.
  Enhanced thermal performance with low E coating available

• Multiple glass lites per door panel (intermediate horizontals) allowing combinations of privacy, clear or tinted glass

• Powder Coating aluminum finish. Meets AAMA 2604 exigencies (5-year warranty) AAMA 2605 is also available (10-year warranty)

• Industry Standard Hardware preparation: 16mm stainless steel Eurogroove Multipoint Lock (8 Points)

• Unlimited design options. Solid panels can combine different materials, such as stainless steel, aluminum and glass to create sophisticated and elegant designs

​Florida Product Approval

FL #26942.2 LMI

Impact Resistant Residential Entry Door

• 4″ frame depth

• Concealed installation screws

• Available with 3-point, multi-point lock

• Available with single & double door configuration

• Heavy-gauge aluminum T6 alloy

• Pre-hung door ready to install

• Extruded aluminum snap-on glazing beads

• Double weatherstripping

• Maximum Width Size: (X) 39 3/4″ (XX) 76″ (OXXO) 148″

• Maximum Height Size: 98″

• Max Size:

• 39 3/4″ x 98″ (X)

• 76″ x 98″ (XX)

• 148″ x 98″ (OXXO)

• Design Pressure: +70/-75 psf

• 7/16″ HS/HS and 3/4″ TMP/HS

• Aluminum applied 4 1/4″ colonial muntins

• High bottom rail (8 1/4”)

• Sidelites

• Energy efficient LoE coatings

•  Glass with argon

• Available Mutins:
  1″ Flat-Flat
  1″ Ogee-Flat
  1″ Ogee-Ogee
  2 1/2″ Flat-Flat
  1/4″ Plain Ogee-Flat

• Available in Colonial, Brittany 6, Brittany 9

Impact Resistant Residential Entry Door

• 9/16″ HS/HS laminated glass

• 3-point lock active leaf / 2-point lock inactive leaf

• 1 5/8″ residential bumper threshold

• Florida Product Approval: Large Missile

• Extruded snap-on glazing bead

• 2 1/2″, 4 1/4″ colonial muntins

• Maximum Frame Depth: 5″

• Maximum Width: (X) 45 9/16″ (XX) 87 1/2″

• Maximum Height: 120″ w/transom 132″

• Design Pressure : +80/-80 psf

• Integral transom

• 10” bottom rail

• Energy efficient LoE coatings

• Glass with argon

• Available Mutins:
  2 1/2″ Flat-Flat
  4 1/4″ Plain Ogee-Flat

• Available in Colonial
