Impact Resistant Horizontal Sliding Window

• Featuring oversized dimensions: 127” x 74”

• Meets Florida Building Code for High Velocity Hurricane Zone.
  Large and Small missile rated

• Sturdy Construction allows for very high wind loads up to 140 PSF

• Glazing applied with high strength silicone for elevated resistance to impact and cyclic loads 2-7/8” deep frame. Glazing Capabilities: Heat strengthened laminated (5/16” & 7/16”) and Insulated glass up to 13/16” thick. Enhanced thermal performance with low E coating available

• OX, XO and XOX configurations available

• Powder Coating aluminum finish for superb quality and environmentally friendly operation. Meets AAMA 2604 exigencies (5 year warranty) AAMA 2605 is also available (10 year warranty)

​​Florida Product Approval

FL #20359.1 LMI – FL #20359.2 SMI

Impact Resistant Horizontal Sliding Window

• Meets HVHZ. LMI Rated

• DP= +/-65 PSF

• Sizes: OX/XO up to 74” x 63” and XOX up to 111” x 63”

• Slim structure to maximize glass view and day light opening

• Extrusions are 2-3/16” deep to have the minimal impact on interior finish during retrofit

• Machine glazed with silicone GE 2000/DS795

• Laminated Heat Strengthened Glass with 0.09 thick PVB as interlayer

• Silicone glazing gasket and stainless steel screws

• Clear, tinted, or reflective glass. Low-e glass for enhanced Solar Heat Gain Coefficient while allowing maximal transparency and visual light transmittance

• Powder coat finish. Standard and custom colors. Meeting AAMA 2604 as standard finish (5 years warranty) with possibility to upgrade to AAMA 2605 (10 years warranty)

• Wheels in PMO (Acetal) for smooth operation

• Aluminum 6063T6 structure

• Colonials for design freedom

​​Florida Product Approval

FL #41890.1 LMI

Impact Resistant Horizontal Sliding Window

• Heavy-gauge aluminum T6 alloy

• Stainless steel assembly screws

• Sweep locks

• Double weather-stripping

• Extruded aluminum snap-on glazing beads

• Bottom Weep Holes

• Flange Frame

• 2 1/8″ Frame Depth

• Maximum Width Size: 74 1/8″

• Maximum Height Size: 63″

• Max Size: 74 1/8″ x 63″

• (Large Missile) Design Pressure: +55/-60 psf

• 5/16″ HS/HS
• 2-panel configuration (OX/XO)
• Florida Product Approved: Large Missile
• Energy efficient LoE Coatings
• Egress sash locks
• Extruded double-applied 1″ colonial muntins
• Available Mutins:
  1″ Flat-Flat
  1″ Ogee-Flat
• Available in Colonial, Brittany 6, Brittany 9

Impact Resistant Horizontal Sliding Window

Impact Resistant Horizontal Sliding Window
